Product name

DM 7x60x20

Explore options

Technical specifications

Base material

Lath size (wx/hx)

Sloted cross bar

No. of blades

Element weight kg/m2

Surface

Fire classification

Humidity resistance

Acoustical treatment

Open area

Suspension

Real wood: Pine, Larch, Birch, Oak etc.

60x20mm

45x35mm+26x35mm

6,80

Standard WB coating , oil /wax coating, staining etc.

B s1.d0 , EU norm EN 13501-

70% standard to 95% treated

Rockfon Industrial mineral fibre pad 20mm or acoustical fleece 155g/m2

30%

Standard plaster board studs or wood trims - direct mount

Explore options

Technical specifications

Base material: Real wood: Pine, Larch, Birch, Oak etc. Lath size (wx/hx): 60x20mm Sloted cross bar: 45x35mm+26x35mm No. of blades: 7 Element weight kg/m2: 6,80 Surface: Standard WB coating , oil /wax coating, staining etc. Fire classification: B s1.d0 , EU norm EN 13501- Humidity resistance: 70% standard to 95% treated Acoustical treatment: Rockfon Industrial mineral fibre pad 20mm or acoustical fleece 155g/m2 Open area: 30% Suspension: Standard plaster board studs or wood trims - direct mount

Graph

Sound absorption

PRODUCT	αw	125	250	500	1000	2000	4000
ADV 2-16+10-16	0.55	0.55	0.75	0.80	0.75	0.65	0.55

PRODUCT	ADV
αw	0.55
125	0.55
250	0.75
500	0.80
1000	0.75
2000	0.65
4000	0.55
